Kingston FURY KF560R32RB-16 2G x 80-bit (16GB) DDR5-6000 CL32 SDRAM
Kingston FURY KF560R32RB-16 2G x 80-bit (16GB) DDR5-6000 CL32 SDRAM
12
People watching this product now!
Description
Kingston FURY KF560R32RB-16 2G x 80-bit (16GB) DDR5-6000 CL32 SDRAM
| Parameter | Specification |
|---|---|
| CAS Latency (CL / IDD) | 40 cycles |
| Row Cycle Time (tRCmin) | 48 ns (min) |
| Refresh to Active / Refresh Command Time (tRFCmin) | 295 ns (min) |
| Row Active Time (tRASmin) | 32 ns (min) |
| Row Precharge Time (tRPmin) | 16 ns (min) |
| UL Rating | 94 V-0 |
| Operating Temperature | 0 °C to +95 °C |
| Storage Temperature | −55 °C to +100 °C |
| Default (JEDEC) | DDR5-4800 CL40-39-39 @ 1.1 V |
| XMP Profile #1 | DDR5-6000 CL32-38-38 @ 1.35 V |
| XMP Profile #2 | DDR5-5600 CL36-38-38 @ 1.25 V |
| XMP Profile #3 | DDR5-4800 CL36-38-38 @ 1.1 V |
| Power Supply – VDD | 1.1 V Typical |
| Power Supply – VDDQ | 1.1 V Typical |
| Power Supply – VPP | 1.8 V Typical |
| Power Supply – VDDSPD | 1.8 V to 2.0 V |
| ECC | x80 ECC (x40, 2 independent I/O sub-channels) |
| On-Die ECC | Supported |
| Internal Banks | 32 |
| Post Package Repair | Hard / Soft |
| Sideband Access | I3C / I2C |
| PCB Height | 1.23 in (31.25 mm) |
| Compliance | RoHS Compliant, Halogen-Free |
Additional information
| Brand | Kingston |
|---|
